Robertshaw® offers direct replacements for several leading OEM brand ignitors. These ignitors are constructed with sturdy, long-lasting silicon nitride for maximum longevity. The Robertshaw 41-426N is a 120V Direct Replacement for Carrier LH33ZG001 with a 8.27 inch wire length and 1.5 inch insulator.

The Robertshaw® 780 Series Pilot Controls Uni-Kits® feature a flame sense circuit that will work equally well on a one rod (local sense) or a two rod (remote sense) application. The automatic recycle features assure that, in the event of flame failure, main gas is disabled and the spark repetition sequence is restarted until pilot gas is ignited. Only after pilot ignition has been re-established can main gas be returned to the burner. The Robertshaw lockout version kits include the capability to shut off all gas to the furnace, should pilot ignition fail to occur after a predetermined time period. The 780-002 provides three tries for ignition. Each ignition period is 90 seconds followed by a six minute time delay between ignition attempts. If the pilot flame is not sensed after three tries, the unit goes into lockout and must be reset at the thermostat.

Features and Benefits

Replaces one rod and/or two rod systems
Reduces truck stock inventory, saving space and money
Includes vent damper adapter assembly
Easy-to-install with complete in-depth installation instructions
Pilot and main valves draw 1 Amp at 0.5 power factor
Combined load at 1.5 Amps at 0.4 power factor
95% relative humidity noncondensing at 104°F

Quick coupler valve depressors complete with neoprene seal and depressor tips

Features/Benefits

1/4" Female Flare Swivel x ¼" Male Flare Access, 90° Configuration
Depressor Tip and Seal, No Valve Core
Made of CDA 360 brass

Exact replacement silicon nitride flat igniter kit with bracket, connector and high temperature wire nuts.

Features:

Superior gas lighting ability
Lower power consumption
Faster time to temperature response
Higher resistance to oxidation


Specifications:

Maximum Temperature: 2732°F / 1500°C @ 132 VAC
Minimum Temperature: 2192°F / 1200°C @ 98 VAC
Time to Temperature (1800°F): < 17 seconds @ 120 +/- 1.0 VAC
Voltage: 120 VAC
Steady State Current: 0.8 - 2 amps @ 120 VAC
Cold Resistance: 34-64 Ohms @ 75°F, +/- 10°F

Model HVAC Port-A-Torch® kit without cylinders contains all the quality equipment needed for brazing, and welding using oxygen and acetylene gases all in a convenient portable carrying case. The kit can braze up to 1 in. (25.4mm) diameter copper tube and is supplied with a size tip for brazing copper up to ½ in. (12.7mm) tube. The kit is capable of welding up to 1/8 in. (3.18mm) and is supplied with a tip that welds up to 1/16 in. (1.6mm) plate.

Features
Light Duty Port-A-Torch® V-Series threaded kit with cylinders designed to be used with oxygen and acetylene gases.
Regulator oxygen and acetylene model 601 with 50mm dual scale plastic gauges, notched adjusting knob and our distinguished internal encapsulated seat filter. Oxygen regulator that delivers up 80 psi and acetylene that regulator delivers up 15 psi.
Torch handle model 15-5HV solid brass torch handle is lightweight with front valves
Consumables included: mixer model 15HV and welding/brazing tip model 5090-1 & 3
Accessories included: Shade 5 safety glasses (ANSI Z87.1 CE Weld), Handheld ignitor, 3/16 in. x 12 ft. AxA twin R-grade hose, No. 5 chrome acetylene cylinder wrench, and black plastic PAT hose reel case.

The Ranco® Dual Pressure Controls combine the functions of a single high-pressure limit control and a single low-pressure control in one unit with a single pole, single throw (SPST) switch.

Features and Benefits

Convertible feature allows selection of manual or reset function when operating at high pressure (O12‑4833/O12-4834)
A wide range of high-pressure manual or automatic reset controls can be replaced (O12-4833 or O12‑4834)
A high-pressure limit is combined with suction pressure sensing to provide temperature control and/or pump down
High-limit adjustment screw
Low-pressure differential and range adjusting screws
Selector screw for manual or automatic
Reset button
Low-pressure scale plate
High-impact plastic cover with center mount screw
High-pressure scale plate
Super Cap® capillary protection system
Color-coded for easy identification of pressure line
High-side capillary flare nut (silver)
Low-side capillary flare nut (brass)

The Ranco® O Series Single Low Pressure Controls offer a variety of pressure ranges and switch action to provide maximum application flexibility.

Features and Benefits

Controls available for most refrigerant types
High-amp rated switch (SPST) design (O10-1402/O10-1483)
Super Cap® capillary vibration protection system
Non-conductive front cover with captive screw
Adjustable differential and range
Easy-to-read scale plate
Vibration cone (absorbs and reduces vibration away from brazed joint)
Low mass copper alloy capillary tube (reduces capillary stress caused by equipment vibration)
The O16-624 control has additional features:

Compatible with refrigerants 134A, 401A, 401B, 402A, 402B, 403A, 403B and 404A

Line service valve 1/8" copper tubing, wrench cap and core

Features/Benefits

⅛" Copper Tubing
Made of CDA 360 brass
Wrench Cap and Core

114N3597 OPTYMA™ OUTDOR SLIM (LOW AMBIENT KIT) LOW 8HP 3PH
Compressor power supply [V]: 230/3/60
LNYM0600UWL000Q

R448A/R449A Capacity range: 27310 BTU/hr (Ambient Temp. = 95°F , evaporating temperature =-10°F), Power consumption 6222W, AWEF 3.39

R404A/R507 Capacity range: 33350 BTU/hr (Ambient Temp. = 95°F , evaporating temperature =-10°F), Power consumption 6360W, AWEF 3.76

Line Service Valve 3/16" Copper Tubing, Wrench Cap and Core

Features/Benefits

3/16" Copper Tubing
Made of CDA 360 brass
Wrench Cap and Core

Model Inferno® kit with HA-3i and HA-8i heating tips contains all the quality equipment needed for brazing, and soldering using acetylene gas. The kit can braze up to 5 in. (127.00mm) diameter copper tube and is supplied with a size tip for brazing copper up to 1 ¼ in. tube. The kit can solder up to 6 in. (152.40mm) diameter copper tube and is supplied with a size tip for soldering copper up to 3 in. (76.20mm) tube.

Features
Kit for brazing and soldering using air acetylene gas with quick connect Inferno® tip interchangeability.
Acetylene regulator model 601 with 50mm dual scale plastic gauges, notched adjusting knob and our distinguished internal encapsulated seat filter. The regulator delivers up 15 psi.
Handle HQB-4 is ergonomically designed with a super tough grip for balance and comfort. This handle features quick connectivity for ease of desired heat output
Consumables included: Heating tips HA-3i and HA-8i made of 304 stainless steel utilizing swirl combustion technology.
Accessories included: Shade 5 safety glasses (ANSI Z87.1 CE Weld), Handheld ignitor, 3/16 in. x 12 ft. AxA single T-grade hose, and chrome acetylene cylinder wrench
Crossover PN : (T)0386-0339, (G)447404
Recommended Accessories - Cylinder, CGA 200 MC Empty - PN 8800336
Conveniently packaged in clamshell for point-of-purchase display

The Robertshaw® 720 Series 24 Volt Dual Gas Valve is a six-function gas valve incorporating a manual valve, safety shut-off magnet, dual automatic valves, main gas regulator, and pilot adjustment. Models are available with and without a pressure regulator. Uni-Kit® models are factory set at 3.5” WC for natural gas, but can be converted to LP by installing the regulator conversion kit included. The wiring connections, manual selector and adjustments are easily accessible on top of the valve. With a 3-9/16” swing radius, the 720 Series lends itself well to replacing many OEM valves. Valve can be mounted in any position except upside down.

Features and Benefits
Gas cock dial marking Off - Pilot - On
Pilot outlet 1/4” tubing
Ambient temperature of -40°F to 175°F
Combination screw/spade terminal type
Maximum inlet pressure 14” WC (0.5 PSI)
Standard NEMA terminals
Inlet filtered screen
Various gas types: natural, manufactured, mixed, LP, and LP/air mixtures
Multiple actuators available
RoHS compliant

Model HA-8i Inferno® air-fuel quick connect swirl tip has a specially-designed insert that delivers reliable swirl combustion performance every time. It provides a consistently hotter flame that will engulf and wrap around the work-piece for maximum efficiency. It is constructed from thick and strong 304 stainless steel tube stock designed to be durable and long-lasting. The tip works and integrates with today's existing quick-connect air-fuel handles allowing contractors to simply and quickly connect to their existing torch handles using acetylene.

Features
Quick connect swirl tip with A-hose connections for brazing and soldering with air/acetylene
Constructed from thick and strong 304 stainless steel tube stock and brass for longer service life
The unique swirl combustion design provides a consistent, hotter flame that engulfs and wraps around the work-piece for maximum efficiency
Every tip is tested twice - once to ensure the perfect orifice and again to ensure the flame quality
The exacting manufacturing standards used to develop this tip ensures the optimal delivery of fuel gas resulting in the perfect flame
Designed to work and integrate with existing quick-connect air fuel handles for efficiency and increased productivity
Tips are configured to produce reliable and repeatable flame performance and are evaluated using thermal photography techniques
Use with air-fuel/acetylene
Marked with Harris logo and tip size for easy identification
One year warranty
Disclaimers
Warning - Cancer and Reproductive Harm - www.P65Warnings.ca.gov

CAPACITOR, OVLD AND START, RLY, 115V, 6.8A

Prevents low voltage starting problems
Replaces relay, overload and provides a boost for hard start and unbalanced systems
Wire designations - white/start, black/common, red/run

The 1830 Series Pilot Uni-Kit® models are designed to be used with all Robertshaw® and most competitive thermocouples. Uni-Kit models include an adaptor that converts a threaded thermocouple/thermopile model 2CH to a snap-in thermocouple type, model 2C.

Features and Benefits

Many flame pattern types available
Thermocouple or thermopile options
Spark electrode available
Horizontal or vertical gas inlet
Several mounting bracket types available
Aerated pilots with non-linting characteristics

Robertshaw® IgnitorPro™ Universal Ignitors are a durable and versatile product contractors can keep on
hand to ensure quick, reliable repairs. These ignitors include all mounting brackets and hardware.

Versatile:
- Replace more than 150 ignitors from leading OEMs
- The perfect truck stock items-minimal inventory
- Round and flat blade designs available
Easy to install: Include all mounting brackets and hardware
Reliable: Constructed with silicon nitride, the new industry standard for durability
- Fewer callbacks
- More repeat business for new installations and preventive maintenance
