Model Inferno® kit with HA-5i and HA-14i heating tips contains all the quality equipment needed for brazing, and soldering using acetylene gas. The kit can braze up to 5 in. (127.00mm) diameter copper tube and is supplied with a size tip for brazing copper up to 3 in. (76.20mm) tube. The kit can solder up to 6 in. (152.40mm) diameter copper tube and is supplied with a size tip for soldering copper up to 5 in. (127.00mm) tube.

Features
Kit for brazing and soldering using air acetylene gas with quick connect Inferno® tip interchangeability.
Acetylene regulator model 601 with 50mm dual scale plastic gauges, notched adjusting knob and our distinguished internal encapsulated seat filter. The regulator delivers up 15 psi.
Handle HQB-4 is ergonomically designed with a super tough grip for balance and comfort. This handle features quick connectivity for ease of desired heat output
Consumables included: Heating tips HA-5i and HA-14i made of 304 stainless steel utilizing swirl combustion technology.
Accessories included: Shade 5 safety glasses (ANSI Z87.1 CE Weld), Handheld ignitor, 3/16 in. x 12 ft. AxA single T-grade hose, and chrome acetylene cylinder wrench
Crossover PN : (T)0386-0336, (G)89628
The quality designed Inferno® tips deliver reliable heat, consistent temperature and a quality flame
Regulator has seven year warranty and other components have one year warranty
Conveniently packaged in clamshell for point-of-purchase display

The Robertshaw® 720 Series Lever Actuated Gas Valves are designed for intermittent pilot ignition applications. This series incorporates a manual valve, pilot valve, dual automatic valves (2), and a main gas pressure regulator. Uni-Kit® models are factory set at 3.5” WC for natural gas, but can be converted to LP by installing the regulator conversion kit included. The 720 Series is designed for many residential applications such as central heating units, space heaters, wall heaters, boilers, and mobile home furnaces. This valve has a compact swing radius of only 3-9/16” to enable it to fit a wide range of OEM replacement applications.

Features and Benefits
Pilot outlet 1/4” tubing
1/4” quick connect terminal type
Ambient temperature of -40°F to 175°F
Maximum inlet pressure 14” WC (0.5 PSI)
Standard NEMA terminals
Rated as NEC Class 2
Inlet filtered screen
Various gas types: natural, manufactured, mixed, LP, and LP/air mixtures
RoHS compliant

Model B15-3HV is an E-equal or positive pressure mixer for light-duty brazing and welding with all fuel gases. This model has a mixer-to-tip tube thread size of 5/16 in. - 27. Its welding capacity is 1/2 in. (12.7mm) plate and it heats up to 60,000 BTU. Typical applications include metal art, maintenance, production brazing, etc. Conveniently vacuum-packed for point-of-purchase display.

Features
Brass light-duty mixer
E-equal or positive pressure mixer
For use with all fuel gases
5/16 in. - 27 mixer-to-tip tube thread size
Thread sealants not required when used with genuine Harris mixers
Welds up to 1/2 in. (12.7mm) plate;Heats up to 60,000 BTU
Typical applications include metal art, maintenance, production brazing, etc.
Engraved with model number for easy identification

Vibration absorbers are designed for installation in the suction and discharge lines of air conditioning, heat pump and refrigeration systems to dampen the transmission of compressor induced vibration through the system piping.

Features/Benefits

100 % helium and hydrogen leak tested
Compatible with all refrigerants
Deep pitch stainless steel hose and high tensile wire braid
Unique proven design for high pressure applications rated for R410A

The Robertshaw® IgnitorPro™ Universal Ignitors are the perfect truck stock item. All universal ignitors replace over 150 ignitors currently used in the field. To allow for universal applications, mounting brackets and hardware are included. Robertshaw IgnitorPro Universal Ignitors are recommended for operating voltage of 120V AC.



Features and Benefits

120V Round Ignitor
Replaces WH Hot Rod 21D64-2
3 Year Limited Warranty
Includes Universal Brackets

The Robertshaw® 1820 Series Pilot Uni-Kit® models are designed to replace hard-to-find ITT-General PG9 type pilots. A special 1/4” tubing adaptor is typically provided with nut and ball sleeve. Uni-Kits are available with and without a 32” (810mm) thermopile.

Features and Benefits

Many flame pattern types available
Thermocouple or thermopile options
Spark electrode available
Horizontal or vertical gas inlet
Several mounting bracket types available
Aerated pilots with non-linting characteristics

Robertshaw® offers direct replacements for several leading OEM brands. These ignitors are constructed with sturdy, long-lasting silicon nitride for maximum longevity. The Robertshaw 41-430N is a 120V Direct Replacement for Lennox 70W16 with a 12.69 inch wire length and a 1.5 inch insulator, with a right angle mounting bracket.

ILVALOY 560 FLUX COATED (Orange)
Product Overview

Silvaloy 560 Flux Coated is a flux coated Silvaloy brazing rod. In addition to bare and cored high silver alloys, we also offer rods that are coated with our general purpose Handy Flux.
Improved joint strength due to less flux inclusions
Minimizes post-braze cleaning
Reduces brazing cycle times
Made in the USA
Industry Applications:
Ferrous and non-ferrous alloys, food handling equipment, refrigeration tubing

The Robertshaw® 785 Series Automatic Pilot Relight Kits are designed for use on rooftop heating equipment, water heaters, boilers, space heaters, unit heaters, dryers, and other commercial, industrial, and residential appliances where the problem of pilot outage may occur. It should only be applied to those systems which already incorporate the necessary pilot-safety control system.

Features and Benefits
Kit Includes: Ignitor Assembly & Mounting Bracket

Universal flat silicon nitride igniter kit. Includes brackets and hardware to replace hundreds of OEM furnace and boiler igniters

Features/Benefits

18 gauge copper high temperature fiberglass insulated lead wires
Faster time to temperature response
Higher resistance to oxidation
Longer usable life
Lower power consumption
More robust in transit
Stronger more durable design

Time to Temperature: <17 seconds @ 120 +/- 1.0 VAC
Resistance: 34 - 64 Ohms
Minimum Temperature: 2192°F / 1200°C @ 98 Volts
Maximum Temperature: 2732°F / 1500°C @ 132 Volts
Steady State Current: 0.8 to 2.0 Amps Maximum @ 120 Volts
Igniter Material: Silicon Nitride

114N3576 OPTYMA™ OUTDOR SLIM (LOW AMBIENT KIT) MED 1.5HP 3PH
Compressor power supply [V]: 230/3/60
OP-HJZM0150UWK000Q

R448A/R449A Capacity range: 10740 BTU/hr (Ambient Temp. = 95°F , evaporating temperature =25°F), Power consumption 1705W, AWEF 8.19

R404A/R507 Capacity range: 12399 BTU/hr (Ambient Temp. = 95°F , evaporating temperature =25°F), Power consumption 2002W, AWEF 7.85

The Ranco® A12 and 9531 Series Constant Cut-in Temperature Controls are designed to switch electrical components of refrigeration systems in response to sensed temperatures.

Features and Benefits

Laser-welded stainless steel bellows
Fixed or adjustable temperature settings
High-amperage contacts
Pneumatic action provided by vapor-filled capillary or capillary with bulb sensing elements
Constant On or Off positions available
Choice of mounting brackets, adjustment ranges and cams, and slotted or flatted shafts
Standard 1/4” quick-connect terminals with optional screw terminals

The Robertshaw® 2374 Series Adjustable Air Sensing Switches are designed to replace a wide variety of air sensing switches found in residential and light commercial applications including furnaces, electronic air cleaners and humidifiers. Two models are currently available with adjustable ranges. Both models are provided with an SPDT switch that can be actuated by positive or negative pressure or by pressure differential. Highly accurate, these switches are practically insensitive to temperature change with an operating temperature range of -40°F to 190°F (-40°C to 88°C). Each switch includes mounting hardware and an adjustment tool for easy installation and calibration.

Features and Benefits
Field adjustable control set point
Air sample line connectors will accept 1/8”, 1/4” or 3/8” tubing
Electrical connection is 1/4” spade
Vertical operating mounting position for diaphragm
UL File Number MH6213, CSA File Number LR18754

A worn clutch can cause a lower spin speed, leaving clothes wet at the end of the cycle. Kit includes brake cam driver, and springs.

Features/Benefits

Fits Whirlpool® direct drive washers
Includes 285790 lining and springs for 24" and 27" machines
See Cross Reference tab for additional numbers

114N3596 OPTYMA™ OUTDOR SLIM (LOW AMBIENT KIT) LOW 6HP 3PH
Compressor power supply [V]: 230/3/60
LNYM0600UWL000Q

R448A/R449A Capacity range: 20630 BTU/hr (Ambient Temp. = 95°F , evaporating temperature =-10°F), Power consumption 5385W, AWEF 3.26

R404A/R507 Capacity range: 25730 BTU/hr (Ambient Temp. = 95°F , evaporating temperature =-10°F), Power consumption 5513W, AWEF 3.53

114N3589 OPTYMA™ OUTDOR SLIM (LOW AMBIENT KIT) MED 6HP 3PH
Compressor power supply [V]: 230/3/60
HRXM0600UWK000Q

R448A/R449A Capacity range: 50610 BTU/hr (Ambient Temp. = 95°F , evaporating temperature =25°F), Power consumption 6504W, AWEF 9.64

R404A/R507 Capacity range: 54180 BTU/hr (Ambient Temp. = 95°F , evaporating temperature =25°F), Power consumption 6264W, AWEF 10.57

The Robertshaw® 780 Series Direct Spark Controls are applicable to commercial cooking equipment, gas fired heating, and water heating systems of many types. The system acts on a demand for heat by a switch or thermostat to open the gas valve. At the same time, the 780 series ignition control supplies a spark to the electrode which ignites the gas. After the gas is lit, an electronic circuit proves the presence of flame using flame rectification. When the thermostat is satisfied, the gas valve will be closed to shut off the main burner gas.

Features and Benefits
Replaces one rod and/or two rod systems
Easy-to-install with complete in-depth installation instructions
Reduces truck stock inventory, saving space and money
